2-18

Symbol

Description

Symbol

Description

No battery

High

-priority information

Identifier: manufacturer

Refer to instruction

manual/booklet

The product complies with EU Medical Devices Directive (93/42/EEC) and

meets the basic requirements in Annex I of the directive, so it has the CE

mark.

Electrical:

WEEE (Waste of Electrical and Electronic Equipment) Marking. Separate

treatment from general waste at end of life.
