2-21

Acronym or Abbreviation Description

Total power

Tpause

Percentage of inspiratory pause time

Tslope

Time for the pressure to rise to target pressure

Trig Window

Trigger window

VCV

Volume control ventilation

Tidal volume

Vti

Inspiratory tidal volume
