2.2.8.4 Three-Slot Module Rack Backplane

The three-slot module rack backplane is a logical forwarding data board mainly used to power

and communicate with the module rack.

This board is configured with module rack software.

Installation position of the three-slot module rack backplane

Three-slot module rack backplane

The backplane is installed on the rear.
