Mindray BS-130 User Manual

5 Fluid System 5-4
NO. Name Material code Model Quantity Remarks
4 Syringe BA30-10-06651 Kloehn17595 1
500ul reagent
syringe
5 Interior pump 0040-10-32313 PML4962-NF30 1
350ml/min，
1.5bar
6 Exterior pump 0040-10-32313 PML4962-NF30 1
350ml/min，
1.5bar
7 Probe BA40-30-61525 / 1
8 Solenoid Valve 0040-10-32300 lEE LFVA1230213H 1
9
Wash pool
module
BA10-20-77752 2 Self made
10
Filter assembly BA31-30-41412
1
Self made
The function of each component is described as below:
1. Check valve (CV): To prevent the deionized water in the tubing from flowing back;
2. Deionized water tank (D1): To provide the clean water for washing the probe and the
mixing bar;
3. Waste tank (D2); To collect the liquid waste which is generated during the operation;
4. Syringe: To accurately deliver the reagent or sample;
5. Interior pump (P1): To provide clean water for washing the inside of the probe;
6. Exterior pump (P2): To provide clean water for washing the outside of the probe;
7. Probe (Needle): To sample the reagent/sample;
8. Solenoid valve (SV): To control the on/off of the pipette pipe, to shift the module
between washing mode and sampling mode;
9. Wash-well assembly (C1, C2): To wash the probe and the mixing bar.
10. Filter (J01): filtrate the impurtiy in the water.
5.5 Connectors
Table 5-2 Connectors List
NO.
Connector
Code
Material code Name and description Quantity
1 J01 BA31-30-41412 Filter assembly 1
M90-100009--- FTLB230-1 2
M90-100050--- CCLR-3 2
2 J02,J05
M90-100014--- LNS-3 2
3 J03,J04 M90-100025--- MTL230-1 2
