5 Fluid System
5-11
5.9.5 Diaphragm Pump
Figure 5-11 Diaphragm pump
Applied assemblies: wash system
Function: The liquid achieves defined pressure and speed through the travel from the
entrance to the exit of the diaphragm pump driven by the electronic power and then is
transported into the wash wells to wash the probe and mixing bar.
5.9.6 Probe
Figure 5-12 Probe (reagent/sample)
Applied assembly: sampling system
Function: Via the controlled up-and-down movements of the syringe, the probe aspirates
and dispenses the reagent or sample.
NF30
