5 Fluid System
5-
5
NO.
Connector
Code
Material code Name and description Quantity
M90-100021--- MLLR-3 2
M90-100009--- FTLB230-1 2
M90-100051--- CCLR-4 2
4 J12,J15
M90-100015--- LNS-4 2
M90-100025--- MTL230-1 2
5 J13,J14
M90-100022--- MLLR-4 2
BA40-20-72949
Barbed connector (pattern
MR72948)
1
6 J06
0040-10-32303
14271 washer
1
0040-10-32304
Upchurch P-208 flangeless
fitting
3
7
J07， J08，
J09
0040-10-32305
Upchurch P-200N flangeless
ferrule for 1/16”OD tubling
3
BA30-20-06758 Tubing retaining bolt 1
8 J10
0040-10-32306
Diba 071-153-031 STAINLESS
STEEL Washer
1
9 J16 M6Q-030043--- Y230-6 1
10 J21 BA10-20-78077
Condensation tubing connector
of reagent disk
1
11 J22,J23 M6Q-030095--- Y670-6 2
12 J24,J29 BA10-20-78001 Nut of waste connector 2
13 J25,J26 BA10-20-78000 Waste connector 2
5.6 Tubing
Table 5-3 General Tubing List
Tubin
g code
Tubing model Material
Inner-dia
meter
(in.)
Outer-diame
ter
(in.)
Max. working
pressure
（
（（
（psig/bar）
））
）
Material code
1#
AAC00028
Rubber
tubing
3/8 9/16
25/1.72
M6G-020047---
2#
AAC00007
Rubber
tubing
1/8 1/4
45/3.11
M90-000025---
3# DB600-10011 PTFE 0.040 0.066 1700/117 0040-10-32301
4# AAX02004 Rubber 3/32 5/32 40/2.76 M90-100071---
Remark: The values of Max. Working Pressure are from original manufacturer’s
recommendation.
