1 System Description 1-1
1 System Description
1.1 Overview
The BS-120/BS-130/BS-180/BS-190 is a fully-automated and
computer-controlled chemistry analyzer designed for in vitro quantitative
determination of clinical chemistries in serum, plasma, urine and CSF
(Cerebrospinal fluid) samples. BS-120/BS-130/BS-180/BS-190 Chemistry
Analyzer consists of the analyzing unit (analyzer), operation unit (personal
computer), output unit (printer) and consumables.
1.2 System Components
BS-120/BS-130/BS-180/BS-190 Chemistry Analyzer realizes the ”two-disk +
one-probe + one-mixing bar” scheme, which means one reaction disk, one
sample/reagent disk, one sample probe and one mixing bar. Reaction disk is
where cuvettes are placed; sample/reagent disk is where sample and reagent
containers are placed; sample probe is used for dispensing R1/R2/S; mixing
bar is used for mixing after S or R2 has been added. The photometric system
adopts filter wheel photometer. The cuvettes are replaced manually after the
tests are finished.
