Mindray BS-130 User Manual

6-10 6 Hardware
LED Mark LED On LED Off Remark
5V
Indication of 5V
power
Exception of 5V power
12V
Indication of 12V
power
Exception of 12V power
3.3V
Indication of 3.3V
power
Exception of 3.3V power
MAIN / /
For debug use only,
can be ignored
REAC / /
For debug use only,
can be ignored
CFG
FPGA is being
configured
Configuration has been
finished
Off after power is on
FILL / /
For debug use only,
can be ignored
FPGA
Flickering indicates
FPGA is running
WASH / /
For debug use only,
can be ignored
STIR / /
For debug use only,
can be ignored
Drive board（
（（
（BA10-30-77757）
））
）
D1-24V
24V works
normally
24V off or erroneously
D2-5V 5V works normally 5V off or erroneously
D3-12V
12V works
normally
12V off or erroneously
D16 Inside pump on Inside pump off
D17 outside valve on outside valve off
D18 outside pump on outside pump off
AD conversion board（
（（
（BA10-30-77759）
））
）
+15V
+15V works
normally
+15V off or erroneously
-15V
-15V works
normally
-15V off or erroneously
+5V
+5V works
normally
+5V off or erroneously
Level detection board（
（（
（BA20-30-75263）
））
）
LED1
Detecting the
liquid surface
No liquid surface signal
The liquid surface
signal also occurs
when the electric
things, such as hands
or metal, contact the
probe,
Reagent refrigeration board（
（（
（BA20-30-75227）
））
）
D3-12VLED
12V works
normally
12V off or erroneously
D4-RED_LED
Reagent
refrigeration
temperature T>10
℃
Reagent refrigeration
temperature T in other
status
D5-YELLOW_LED
Reagent
refrigeration
temperature T<0
℃
Reagent refrigeration
temperature T in other
status
