7 Service and Maitenance 7-31
3
CAUTION
When trying to pull out the bar, concentrate your force in the
direction of the axis on the bar arm. Biased force may
damage the bar and/or the axis.
Pinch the bar by the knurled part with one hand and unscrew
(counter-clockwise) the retaining nut with the other hand until the mixing
bar looses. Pull the bar downward to remove it and remove the nut.
4
Align the new mixing bar to the bigger hole end of the retaining nut and
gently screw it into the nut until the end of the bar is in line with the smaller
hole end of the nut.
5
Pinch the mixing bar by the knurled part and align the hole of the nut to
the axis on the bar arm, then push the bar upward in the direction of the
axis until it can’t proceed. Tighten the nut by screwing clockwise with the
other hand.
CAUTION
When trying to pull out the bar, concentrate your force in the
direction of the axis on the bar arm. Biased force may
damage the bar and/or the axis.
Ensure the bar is all the way pushed to the end.
6
After replacing the bar, visually check whether the bar is vertical to the bar
arm.
If not, remove the bar and re-install it.
If yes, proceed to the next step.
