7 Service and Maitenance 7-39
7
Select Purge Combination from the Instructions list, and enter
digit “25” in the edit boxes to the right of Purge A and Purge B.
Select Execute to start the purge cycle based on the parameters
you have entered.
8 Select Maintenance Cycle from the Instructions list and select
Execute.
9 Place the Power to OFF.
10 Remove the electrodes.
11 Seal the hole on the reference electrode with “insert” shown in the
following figure.
Red sphere
Insert
12 Aspirate a small amount of Calibrant A from the port of the reagent
module with a syringe and inject it into the lumens of the K+
electrode(and Li+ electrode) until the lumens are full.
Cover both ends of the lumens with tapes to prevent the Calibrant
A flowing from the lumens.
Put the K+ electrode and Li+ electrode into their individual sealed
bags.
13 Remove the reagent pack.
14 The tube adapters on Reagent Pack should be covered by the red
caps. Store the Reagent Pack properly.
