8-14 8 Test and Maintenance Software
NOTE
If not necessary, please do not use this method to modify
parameters.
If really necessary, restart the analyzing unit and double check to
confirm the modification of the parameter after configuration,
After the parameter configuration is validated, restore the socket
J15 on main board to the status of parameter write protection.
If it is not necessary to validate the modified parameters perpetually, you can restore the
previous parameters after restarting. Please follow the instructions as below:
Click the Setup button on the higher-right area of the software shown in Figure 8-13, input
bs120 to the dialog box, and then click OK.
Figure 8-13 Enable Modifying Parameters 1
2) There is System instruction under each unit name. Please change the value of byte 8
from 00 to 03 in the system instruction, and then click Run to validate the configuration.
The following figure takes the reaction unit as an example.
