1 System Description 1-4
12.
When a batch of analysis is finished or all the cuvettes are used up,
replace the cuvettes manually.
Table 1-1 Functions of System Units
UNIT NAME DESCRIPTION
Sample probe unit
Aspirates and dispenses samples and reagents for all
chemical and ISE tests.
Sample/Reagent
Disk Unit
36 positions.
Default: 1~8# sample position; 9~36# reagent position.
Reaction Disk Unit
Able to hold 40 cuvettes. It provides an environment in
which sample reacts with reagents.
Mixing Unit
Used to stir the mixture in reaction cuvette when
sample or R2 is dispensed.
Photometric Unit
Adopts filter wheel structure and performs photometric
measurement (absorbance reading) at 8 wavelengths.
ISE Unit (optional)
ISE (Ion Selective Electrode) module (not installed on
domestic product).
