Mindray SynoVent E5 User Manual

10-4
10.2 Disassemble the Ventilator’s Cleanable Parts
10.2.1 Expiration Valve Assembly
A. Expiration valve locker knob B. Expiration valve assembly
 To disassemble the expiration valve assembly:
Push the expiration valve locker knob toward the inspiratory port and then pull out the
expiration valve assembly with force.
 To install the expiration valve assembly:
Push the expiration valve assembly into the corresponding connector and make sure that
it is in position.
B
A
