Mindray SynoVent E5 User Manual

B-5
Expiratory resistance
Not greater than 6 cmH
2
O at 60 L/min flow (adult reusable
breathing hose )
Not greater than 6 cmH
2
O at 30 L/min flow (pediatric reusable
breathing hose )
Not greater than 6 cmH
2
O at 5 L/min flow (infant reusable
breathing hose)
Bacterial filter
Resistance: < 2 cmH2O at 60 l/min
Particle size: Captures particles of 0.3 mm (micron) with > 99.99%
efficiency
Dead space：< 80 mL
Leakage
Leakage
Not greater than 200mL/min@50cmH
2
O
Not greater than 100mL/min@40cmH
2
O
Not greater than 50mL/min@20cmH
2
O
B.6 Ventilator Specifications
Controlled parameters
Parameter Range Step Unit
O
2
% 21 to 100 1 ％
TV Pediatric: 20 to 300
Adult: 100 to 2000
Pediatric: 1
Adult: 10
mL
f Pediatric: 1 to 150
Adult: 1 to 150
1 bpm
fSIMV 1 to 60 1 bpm
Tinsp 0.2 0 to 10 0.05 s
I:E 4:1 to 1:10 0.5 /
Flow
1
Pediatric: 6 to 30
Adult: 6 to 120
1 L/ min
Maximum flow
2
180 / L/min
Tslope 0 to 2.00 0.05 s
Plimit 5 to 105 1 cmH
2
O
PEEP OFF, 1 to 45 1 cmH
2
O
Pinsp 5 to 100 1 cmH
2
O
△Psupp 0 to 100 1 cmH
2
O
Phigh 0 to 100 1 cmH
2
O
1
Note: It refers to the inspiratory flow which can be setted for Volume Control modes.
2
Note: It refers to the maximum inspiratory flow for Pressure Control and Pressure Support Ventilation
modes.
