Mindray SynoVent E5 - Enter Standby; Turn the System off

6-23
TVe The expired tidal volume in one cycle.
TVe/IBW The expired tidal volume in one cycle per IBW.
TVe spn The spontaneous expired tidal volume in one cycle.
MV The accumulated expired tidal volume in one minute.
MVspn The accumulated spontaneous expired tidal volume in one minute.
MVleak
The accumulated leakage (inspiratory volume minus expiratory volume) in one
minute.
ftot The accumulated number of breaths in one minute.
fmand The accumulated number of mandatory breaths in one minute.
fspn The accumulated number of spontaneous breaths in one minute.
Ri The airway resistance during inspiration.
Re The airway resistance during expiration.
Cstat The static compliance.
Cdyn The dynamic compliance.
RSBI Rapid shallow breath index that is defined as fspn/TVespn.
WOB Work of breath.
NIF Negative inspiratory force.
P0.1
The pressure drop in the first 100 ms when the patient starts spontaneous
breathing.
PEEPi
Intrinsic PEEP(The PEEPi value displayed has already included PEEP value and
is the actual airway pressure).
Vtrap The volume of trap gas in the lungs produced by intrinsic PEEP.
FiO2 The percentage of oxygen in the patient’s inspired gas.
EtCO2 The concentration of CO2 measured at the end of expiration.
FiCO2 The minimum CO2 concentration measured during inspiration.
6.11 Enter Standby
Push the Standby key. Standby screen appears after your confirmation.
6.12 Turn the System off
Push the key to turn the system off when in Standby. In non-Standby, push the
key and the system prompts [Please enter Standby mode to shut down the system.]. Select
[Ok] to close the dialog. The system is still in non- Standby.
