Mindray SynoVent E5 - Install the Display Onto the Pendant

3-2
1. Put the display onto the ventilator and align the display with the screw holes.
2. Install the three screws to fix the display.
3. Insert the three screw plugs.
4. Connect the display connection line to the Video input/output port and tighten the two
fixing knobs.
3.1.2 Install the Display onto the Pendant
A
E
B
D
C
