B-12
B.11 Compressor Specifications
Compressor Specifications
Input voltage 220 to 240 V 110 to 120 V
Input frequency 50/60Hz 60Hz
Input current 3A 6A
Output pressure range 300 to 450 kPa
Noise Less than 50dB (A)
Continuous flow ≥30 L/min at output pressure of 300kPa
Peak flow Greater than 180 L/min for more than 0.8 seconds at one
barometric pressure
Dew point Lower than the room temperature by 5℃ at flow of 30 L/min
B.12 O
2
Sensor Specifications
O2 sensor
Output 9 to13 mV at 210 hPa O2
Range 0 to 1500hPa O2
100% O2 signal deviation 100±1%
Resolution 1 hPa O2
Expected service life 1.5 x 106 % for measurement (20°C)
0.8 x 106 % for measurement (40°C)
Response time ((21% air to 100% O2) <15s
Linearity Linear 0-100% O2
Operating temperature range -20°C to +50°C
Temperature compensation ±2% of fluctuation at 0-40°C
Pressure range 50 to 200 kPa
Relative humidity 0 to 99%
100% O2 concentration output drift Over one year of typical value <5%
Material White ABS
Packaging Sealed package
Period of validity Not more than 13 months after unpacked (in compliance
with the conditions specified by the manufacturer)
