Mindray SynoVent E5 User Manual

3-15
WARNING
 When installing the humidifier, make sure that the humidifier connector shall be
lower than the ventilator’s breathing connectors and the patient when installing
the humidifier.
3.8 Install the Nebulizer
A. Nebulizer connector B. Nebulizer hose C. Nebulizer
1. Connect one end of the nebulizer hose to the nebulizer connector and the other end of
the hose to the nebulizer.
2. Mount the nebulizer onto the inspiratory hose via the hose.
Note
 The nebulizer assembly and its installation steps described here are only for
reference.
A
B
C
