5-1
5 System Settings
5.1 Change Display Settings
5.1.1 Waveforms
1. Push the Menu key. Select [Display] and then [Waveforms].
2. Select the waveforms to be displayed.
3. Select [Draw Wave] and toggle between [Curve] and [Fill].
[Curve]: the waveform is displayed as a curved line.
[Fill]: the waveform is displayed as a filled area.
5.1.2 Spirometry Loops
1. Select [Spirometry].
2. Select the loops to be displayed.
5.1.3 Measured Values
On the waveforms, spirometry loops, or trends screen, the right side of the screen is divided
into three parameter areas which are Parameter Area 1, Parameter Area 2, and Parameter Area
3 from the top down. To change the parameters to be displayed in each parameter area:
1. Press the Menu key. Select [Display] and then select [Values].
2. Select the parameters to be displayed.
Parameter
Area 1
Parameter
Area 2
Parameter
Area 3
To Next Page
