Mindray SynoVent E5 User Manual

10-8
10.2.5 Nebulizer
A. Nebulizer connector B. Nebulizer hose C. Nebulizer
 To disassemble the nebulizer:
1. Pull out the nebulizer hose from the nebulizer connection.
2. Pull out the nebulizer from the inspiratory hose.
 To install the nebulizer:
1. Connect one end of the nebulizer hose to the nebulizer connector and the other end of
the hose to the nebulizer.
2. Mount the nebulizer onto the inspiratory hose via the hose.
Note
 The nebulizer assembly and its installation steps described here are only for
reference.
A
B
C
