Mindray SynoVent E5 User Manual

B-6
Plow 0 to 50 1 cmH
2
O
Thigh 0.2 to 30 0.1 s
Tlow 0.2 to 30 0.1 s
Trigger 0.5 to 15 0.1 L/min
-10 to -0.5 0.5 cmH
2
O
△int.PEEP OFF, 1 to 40 1 cmH
2
O
Exp% Auto, 10 to 85 5 %
△Papnea Provides pressure apnea setting. Refer to Pinsp specification.
fapnea Pediatric: 1 to 100
Adult: 1 to 100
1 bpm
Weight
Pediatric 3 to 35 0.5 kg
Adult 10 to 200 1 kg
Monitored parameters
Parameter Range Resolution Unit
Ppeak
-20 to +120 1 cmH
2
O Pplat
Pmean
PEEP 0 to 120 1 cmH
2
O
TVi
0 to 4000 1 mL
TVe
TVe spn
MV
0 to 100 0.1 L/min
MVspn
MVleak
ftot
0 to 200 1 bpm
fmand
fspn
Rinsp 0 to 600 1 cmH
2
O/(L/s)
Rexp 0 to 600 1 cmH
2
O/(L/s)
Cstat 0 to 300 1 mL/cm H
2
O
Cdyn 0 to 300 1 mL/cm H
2
O
RSBI 0 to 9999 1 1/(min·L)
WOB 0 to 100 1 J/min
NIF -45 to 0 1 cmH
2
O
