E-5
I:E 1:2
Assist ON
F-Trig Adult: 2.0 L/min; pediatric: 1.0 L/min
ATRC (only in non-NIV
mode)
OFF
Tube diameter (only in
non-NIV mode)
8.0mm
Compensation proportion
(only in non-NIV mode)
80%
Compensation of expiration
(only in non-NIV mode)
ON
Duolevel
O2% 40%
△Psupp 0 cmH2O
Tslope 0.2s
Phigh 15 cmH2O
Plow 5 cmH2O
Thigh Adult: 1.7s; pediatric: 0.7s
Tlow Adult: 3.3s; pediatric: 1.4s
F-Trig Adult: 2.0 L/min; pediatric: 1.0 L/min
Exp% Auto
△Papnea 15 cmH2O
fapnea Adult: 12 bpm; pediatric: 29 bpm
ATRC (only in non-NIV
mode)
OFF
Tube diameter (only in
non-NIV mode)
8.0mm
Compensation proportion
(only in non-NIV mode)
80%
Compensation of expiration
(only in non-NIV mode)
ON
APRV
O2% 40%
Tslope 0.2s
Phigh 15 cmH2O
Plow 5 cmH2O
Thigh Adult: 1.7s; pediatric: 0.7s
Tlow Adult: 3.3s; pediatric: 1.4s
