⑨ Writing the comparison set data (Host → CSD-892-73)
2 4 6 8 10 12 14
@ 0 0 6 0 Terminator
In normal operation
Return (CSD-892-73 → Host)
2 4 6 8 10 12 14
@ 0 0 6 0 Terminator
In abnormal operation
Return (CSD-892-73 → Host)
2 4 6 8
@ 0 0 E R 1 3 Terminator
Command No. Operation
60 Writing S1 setting value
61 Writing S4 setting value
62 Writing S5 setting value
63 Writing S2 setting value
64 Writing S0 setting value
66 Writing FULL(SET8)
67 Writing NEAR ZERO(SET7)
Set value
Sign
Command No.
Set value
Sign
Command No.
• The load data enters from the right.
• Please do not add the decimal point.
• Please set the stored place to [Internal RAM] when the set data is continuously
changed, and the rewritable time of [EEPROM] might exceed about one million
times.
• Please do not change in the set value under the measurement because the A/D
sampling rate decreases temporarily while rewriting the set value when the store
d
place of set data is [EEPROM]. Please set the stored place to Internal [RAM] if
you change the set value under the measurement. Please refer to [6-10.
• Change of data stored place] for the details of setting method of stored place.
The condition of error transmission is as follows:
• When you set the value that exceeds the regular value.
• When you set the character other than the numeric in the set value.
• When you set excluding + or - in the si
gn section.
