4) Remote register
4 stations occupied (CSD-892-73 → Master)
Station Remote register Contents Remarks
1
RWwn
① Net value
RWwn+1
RWwn+2
② Gross value
RWwn+3
2
RWwn+4
Undefined
RWwn+5
RWwn+6 ③ Error code
RWwn+7 ④ Error assistance code
3
RWwn+8
Undefined
RWwn+9
RWwn+A
RWwn+B
4
RWwn+C
⑤ General data area
RWwn+D
RWwn+E ⑥ Command No. (Return)
RWwn+F ⑦ Operating mode (Return)
n : Value decided by setting of station No.
2 stations occupied (CSD-892-73 → Master)
Station Remote register Contents Remarks
1
RWwn
⑧ Indicated value
(Net value / Gross value)
RWwn+1
RWwn+2 ③ Error code
RWwn+3 ④ Error assistance code
2
RWwn+4
⑤ General data area
RWwn+5
RWwn+6 ⑥ Command No. (Return)
RWwn+7 ⑦ Operating mode (Return)
n : Value decided by setting of station No.
1 station occupied (CSD-892-73 → Master)
Station Remote resister Contents Remarks
1
RWwn
⑧ Indicated value
(Net value / Gross value)
RWwn+1
RWwn+2 ③ Error code
RWwn+3 ④ Error assistance code
n : Value decided by setting of station No.
