16
Calibration
4. Calibration mode
4-1. What is calibration?
The calibration is an operation that matches the load of the sensor to the display of this
instrument to display the electrical signal from the sensor (load cell) as an accurate load.
If the calibration is not proceeded, a correct display and an output cannot be taken. The
example when the load cell is used is shown as follows.
For instance, when you put t
he weight of 100 kg on the weighing section.
When calibration is executed ･･･
When calibration is not executed ･･･
Neither the load value, the unit nor
the decimal point display position,
etc. are correctly displayed.
100kg100kg
A correct load value is displayed, and
a unit and a decimal point display
position are displayed as set.
100kg100kg
