3) Command list
The command No. and the value which is set in General data area when the command
order is executed by using the general command request (request 2) are shown in the
next page.
Writing set value and command order (Writing/Reading selection = Writing [OFF])
Setting value or command order
Command No.
(RWwnE)
General data area
(RWwnC ~ RWwnD)
Undefined 1
Undefined 2
Undefined 3
Undefined 4
Undefined 5
Final / S1 6
Free fall / S4 7
Preliminary 1 / S3 8
Preliminary 2 / S2 9
Over / S0 10
Under 11
Near zero 12
Full 13
Undefined 14
Undefined 15
Undefined 16
Undefined 17
Undefined 18
Undefined 19
Undefined 20
Undefined 21
Undefined 60
Undefined 61
Undefined 62
Undefined 63
Undefined 64
ZERO 0 1
ZERO clear 0 2
Tare weight cancellation 0
3
Tare weight cancellation clear 0 4
Undefined 0 5
Undefined 0 7
Undefined 0 10
Undefined 0 11
Undefined 0 12
Undefined 0 13
Undefined 0 14
Undefined 0 15
Undefined 0 21
Undefined 0 22
Display of net value 0 23
Display of gross value 0 24
