14-5. Address map
14-5-1. Data detail
1) Batch/Discharge mode Remote register
4 stations occupied (Master → CSD-892-73)
Station Remote register Contents Remarks
1
RWwn
① Final (24 bit)
Special data area
RWwn+1
RWwn+2
① Preliminary 2 (32 bit)
RWwn+3
2
RWwn+4 ① Preliminary 1 (16 bit)
RWwn+5 ① Free Fall (16 bit)
RWwn+6 ① Over (16 bit)
RWwn+7 ① Under (16 bit)
3
RWwn+8
① Full (32 bit)
RWwn+9
RWwn+A
① Near zero (32 bit)
RWwn+B
4
RWwn+C
② General data area
RWwn+D
RWwn+E ③ Command No. (Return)
RWwn+F ④ Operating mode (Return)
n : Value decided by setting of station No.
2 stations occupied (Master → CSD-892-73)
Station Remote register Contents Remarks
1
RWwn
① Final（32 bit)
Special data area
RWwn+1
RWwn+2 Undefined (16 bit)
RWwn+3 ① Free Fall (16 bit)
2
RWwn+4
② General data area
RWwn+5
RWwn+6 ③ Command No. (Return)
RWwn+7 ④ Operating mode (Return)
n : Value decided by setting of station No.
1 station occupied (Master → CSD-892-73
Station Remote resister Contents Remarks
1
RWwn
Undefined
RWwn+1
RWwn+2
RWwn+3
n : Value decided by setting of station No.
• Please set the stored place to [Internal RAM] when the set data is continuously
changed, and the rewritable time of [EEPROM] might exceed about one million
times.
• Please do not change in the set value under the measurement because the A/
D sampling rate decreases temporarily while rewriting the set value when the
stored place of set data is [EEPROM]. Please set the stored place to Internal
[RA
M] if you change the set value under the measurement. Please refer to [6-10.
Change of data stored place] for the details of setting method of stored place.
81
CC-Link
