53
Setting of Function
8-8.External control I/O
The external control I/O is set.
8-8-1. Setting of external control input
The operation of external control input is selected by the setting of function F-60 ~ F62.
Setting range：00 ~ 10
：00
00：OFF No setting
01：ZERO set Execute the operation of ZERO set
02：ZERO clear When ZERO set and ZERO tracking is executed,
this returns the condition of display before.
03：Tare weight cancellation
Execute the tare weight cancellation
04：Tare weight cancellation clear
When tare weight cancellation is executed, this returns
the condition of display before.
05：Changeover of NET/GROSS value
Changeover the display of NET/GROSS value.
06：HOLD (Pulse) Changeover ON/OFF of HOLD when the signal of
50 msec or more is input.
07：HOLD (Level) Turn ON condition of HOLD during input, when the
signal of 50msec or more is input.
08：NET value display Display NET value in the measurement mode.
09：Batch key lock When the signal of 50 m
s or more in the condition
of measuring display is input, all the key operations
are prohibited during this input.
The key can be operated regardless of the signal
excluding the measurement mode.
10：ERROR release ZERO set error and tare weight cancellation error is
released.
The above mentioned [07 : HOLD (Level)], [08 : NET value display] and [09 : Key lock] are
le
vel input and become effective by the continuous short circuit of 50 ms or more. Other items
are pulse inputs, and become effective once by pulse width of 50 ms or more.
• As for a batch key locking by the external input and an individual key locking
by the function, the operation is different. Even if the [F/ENTER] key is pushed
together with [FUNC.] key, the operation of [FUNC.] key doesn't become
possible.
