Setting of Function
8-8-2.Setting of external control output
The operation of external control output is selected by the setting of function F-70 ~ F-74
Setting range:00 ~ 17
:00
00:OFF No setting
01:STABLE Output during stable
02:DURING TARE Output when tare weight cancellation is executed.
03:GROSS DISPLAY Output when display is the gross value.
04:NET DISPLAY Output when display is the net value.
05:CENTER OF ZERO Output in the condition of the center zero.
06:DURING HOLD Output during the operation is holding.
07:ERROR Output when the error
occurs.
08:ABNORMAL ERROR Output when OL condition is satisfied.
09:NEAR ZERO Output in near zero.
10:OK/S0 Output when the measuring value is OK.
When measurement mode is set to 5-steps
comparator mode, the signal is output at the time
of S0 output condition is satisfied.
11:FULL FLOW/S1 Output when FULL FLOW is executed.
When measurement mode is set to
5-steps
comparator mode, the signal is output at the time
of S1 output condition is satisfied.
12:MIDIUM FLOW/S2 Output when MIDIUM FLOW is executed.
When measurement mode is set to 5-steps
comparator mode, the signal is output at the time
of S2 output condition is satisfied.
13:DRIBBLE FLOW/S3 Output when DRIBBLE FLOW is executed.
When measure
ment mode is set to 5-steps
comparator mode, the signal is output at the time
of S3 output condition is satisfied.
14:OVER/S4 Output when the measuring value is over.
When measurement mode is set to 5-steps
comparator mode, the signal is output at the time
of S4 output condition is satisfied.
15:UNDER Output when the measuring value is UNDER.
16:FULL
Output when the measuring value is FULL.
17:RUN Output in the measurement mode.
8-8-3. External control output logic
The external control output logic is changed by the setting of function F-83.
The external control output operates according to the set logic.
Setting range:00000 ~ 11111
:00000
0:Negative logic
1:Positive logic
Each digit corresponds to OUTPUT1 ~ 5, and can select logic individually.
10
0
digit:Operation of OUTPUT1
10
1
digit:Operation of OUTPUT2
10
2
digit:Operation of OUTPUT3
10
3
digit:Operation of OUTPUT4
10
4
digit:Operation of OUTPUT5
