17-2. External control I/O chapter
Event Please confirm here. Reference
A set item of simple
calibration mode is not
displayed.
Is not the measurement mode set to 5-steps comparator
mode?
11-1.
A set item of 5-steps
comparator mode is not
displayed.
Is not the measurement mode set to simple calibration mode? 11-1.
The external control
input doesn't operate.
Do you correctly connect the equipment? 2-5.
Is the allocation of the external control o
utput correctly set? 8-8-1.
Is the signal of 50 ms or more input for the pulse input? -
Is the signal input at the level input of 50 ms or more
continuously?
-
The external control
output doesn't operate.
Do you correctly connect the equipment? 2-5.
Is the allocation of the external control output correctly set? 8-8-2.
Is the setting of measurement value / comparison value within
the range of setting?
11-2-2.
11-3-2.
Are the voltage and the electric current for an open collector
used within the specification value?
Vce = DC35 V, Ic = DC50 mA max.
2-5.
The logic of an external
output is not suitable.
You want to reverse the
logic.
Please execute a logical change of the external output. 8-8-3.
17-3. CC-Link interface chapter
Event Please confirm here. Reference
The communication is
not normal.
Is the cable for CC-Link interface correctly connected? 2-6.
Is the length of the cable for CC-Link interface within the
regulation that CC-Link society provides?
-
Is the terminating resistance correctly connected? 2-6.
Are the number of occupied station, the station number,
the baud rate and the method of 32 bit data representation
corre
ctly set?
14-3-1.
~ 14-3-4.
You want to confirm the
setting station number
easily.
Please allocate the confirmation of station number for CC-Link
interface to F/ENTER key by that operation setting.
8-7.
17-4. USB interface chapter
Event Please confirm here. Reference
The communication is
not normal.
Is the USB driver installed in the host side?
Please install after downloading from our homepage.
-
Is the port normally recognized on the host side?
Please download [USB interface driver install manual] from
our homepage, and confirm the details.
16
Is the length of USB cable within 5 m regulated? -
are the command mode and the stream mod
e correctly set? 16-2
137
Trouble Shooting
