18-1. Specifications for analog
Bridge power supply DC5 V ± 0.25 V within 60 mA, with sensing
Applicable transducer
Up to 4 pieces of strain gage applied transducers (350 ohm) can be
connectable.
Input sensitivity
0.15 μ V/d or more (d ＝ minimum scale)
* 0.2 μ V/d (In case of applying CE conformity standard.)
Input range -3.1 mV/V to 3.1 mV/V
ZERO adjustable range ± 2.5 mV/V
Non-linearlty 0.01%F.S.
Temp.
coefficient
ZERO
± 0.2 μ V/℃
(In the calibration
by the input sensitivity of 0.15 μ V/d or more.)
Sensitivity
± 0.001 5 %F.S./℃
(In the calibration by the input sensitivity of 0.15 μ V/d or more.)
Input noise
± 0.2 μ Vp-p or less (At the default setting of analog filter, digital filter
and stabilization filter.)
Analog filter Approx. 4 Hz (Changeable to 2Hz, 6Hz, 8Hz or 10Hz)
A/D sampling 500 times/s (Changeable to 250 times/s, 100 times/s or 50 times/s.)
A/D
internal resolution 24 bits
18-2. Specifications for digital
Load display
Display range -99 999 ~ 99 999
Display increment 1 (Changeable to 2, 5, 10, 20 or 50)
Display unit FSTN liquid crystal (With umber color LED back light.)
Over display [-OL] display at minus over, [OL] display at plus over
AD value over display [-OVF] display at minus over, [OVF] display at plus over
Condition display
ZERO, SPAN, mV/V, STABLE, TARE, GROSS, NET, CZ, LOCK, HOLD,
ERROR
Display rate 2 t
imes/s
Judgement display OUT1, 2, 3, 4, 5
Decimal point display Changeable to No display, 10
1
, 10
2
,10
3
or 10
4
.
Unit display Changeable to No display, g, kg, t, N, kN, lb, Pa, kPa or MPa.
18-3. Interface
External control input
3 functions in the following can be arbitrarily selected.
OFF, SERO set, ZERO clear, Tare weight cancellation, Tare weight
cancellation clear, Hold, Net/Gross value
* Above are pulse input, and effective only once at the pulse width of 50
ms or more.
Hold, NET value display (With ON, a NET weight is displayed when the
Gross weight is shown.)
* Above are level input, and effec
tive during the input of short for 50 ms
or more.
External control output
5 functions in the following can be arbitrarily selected.
OFF, RUN, Stable, During canceling the Tare weight, Display of
gross value, Display of net value, Center zero, During the hold, Error,
Abnormal weight, Near Zero, OK (S0), Full flow (S1), Medium flow (S2),
Dribble flow (S3), Over (S4), Under, Full
