16-4. Data format for stream mode
① When the setting of function F-41 is set to [Load display], [Gross value] or [Net value].
(CSD-892-73 → Host)
2 4 6 8 10 12 14
@ 0 0 9 9 Terminator
2 4 6 8 10 12 14
@ 0 0 9 9 - 1 2 3 Terminator
2 4 6 8 10 12 14
@ 0 0 9 9 + 0 . 1 2 3 Terminator
2 4 6 8 10 12 14
@ 0 0 9 9 + O L Terminator
2 4 6 8 10 12 14
@ 0 0 9 9 - O L Terminator
Sign of load data
Command No.
Load data
• The sign of [-] for minus and [+] for plus is entered.
• The load data performs zero suppress.
• The decimal point is put to a specified position when the decimal point is set with
F-46 and also when decimal point is specified with CF-01.
• [OL] is put out to the load data section at the overload. [-OL] is put out to the load
data section when Gross value is in the minus condition.
• The empty section
s are all spaces.
125
USB (RS-232C)
