In CSD-892-73, each data is stored in internal RAM and EEPROM as follows.

The data in EEPROM can be stored almost permanent due to nonvolatile.

12-1. Data stored in internal RAM

• Tare weight cancellation (Saving to EEPROM is also possible.)

• ZERO set data (Saving to EEPROM is also possible.)

• ZERO tracking data

12-2. Data stored in EEPROM

• Calibration data

• Function data

• C function data

• S function

data

• Digital linearize data

• Set data of simple comparison data (FINAL, FREE FALL, PRELIMINARY 1,

PRELIMINARY 2, OVER, UNDER, NEAR ZERO, FULL)

• Set data of 5-steps comparator mode (S0, S1, S2, S3, S4, NEAR ZERO and FULL)

12-3. Data that stored place can be changed

• ZERO set data

• Tare weight cancellation data

The above-mentioned data can select the preservation place from [Internal RAM] or

[EEPROM

The stored place of data is set by the setting of C function CF-17.

Please refer to [6-10. Change of data stored place].

Default has set to [Internal RAM] for both data.

12.

Stored data of setting data

• Please do not change in the set value under the measurement because the A/D

sampling rate decreases temporarily while writing data to EEPROM.

• The data stored in internal RAM is not backed up.

• Please set the stored place to [Internal RAM] when the set data is continuously

changed, and the rewritable time of [EEPROM] might exceed about one million

times.

• Please do not change in the set value under the measurement because the A/

D sampling rate decreases temporarily while rewriting the set value when the

stored place of set data is [EEPROM]. Please set the stored place to Internal

[RA

M] if you change the set value under the measurement. Please refer to [6-10.

Change of data stored place] for the details of setting method of stored place.
