Setting of Function
6. Various operations by C function data
6-1.Decimal point display position
The decimal point display position is selected by C function CF-01.
Setting range : 0 ～ 4
0：Nothing
1：1234.5
2：123.45 3：12.345
4：1.2345
6-2.A/D sampling
The A/D sampling rate is selected by C function CF-02
Setting range：0 ～ 3
0：50 times/s 1：100 times/s
2：250 times/s 3：500 times/s
6-3.Condition of overload display
(Display of [OL] and [-OL])
The overload display condition is selected by C function CF-03.
Setting range：0 ～ 2
0：At exceeding over
∣
Weighing capacity ＋ 9D
∣
1：At exceeding over [ ± 110 % of weighing capacity]
2：At exceeding over [-20D ～（Weighing capacity + 9D)]
6-4. Comparison operation display synchronization
[VALID] or [INVALID] of comparison operation display synchronization is selected by C
function CF-04.
At the selection of [INVALID], the comparison operation synchronizes with A/D sampling
rate, and at the selection of [VALID], it synchronizes with display.
Setting range：0,1
0：Invalid
1：Valid
6-5. Unit
Unit is selected by C function CF-05.
Setting range：0 ～ 9
0：Nothing 1：g 2：kg
3：t 4：lb 5：N
6：kN 7：Pa 8：kPa
9：MPa
• The A/D sampling rate decreases temporarily while writing data in EEPROM.
