16-3. Command data format
① Reading out the load data (Host → CSD-892-73)
When command No.20 ～ 23
2 4 6
@ 0 0 2 2
Terminator
Return (CSD-892-73 → Host)
2 4 6 8 10 12 14
@ 0 0 2 2 Terminator
2 4 6 8 10 12 14
@ 0 0 2 2 - 1 2 3 Terminator
2 4 6 8 10 12 14
@ 0 0 2 2 + 0 . 1 2 3 Terminator
2 4 6 8 10 12 14
@ 0 0 2 2 + O L Terminator
2 4 6 8 10 12 14
@ 0 0 2 2 - O L Terminator
Command No. Operation
20 Reading out load data
21 Reading out gross value
22 Reading out net value
23 Reading out tare value
26 Reading out load data with condition
Load data
Sign of load data
Command No.
Command No.
• The load data enters from the right.
• The sign of [-] for minus and [+] for plus is entered.
• The load data performs zero suppress.
• The decimal point is put to a specified position when the decimal point is set with
F-46 and also when decimal point is specified with CF-01.
• [OL] is put out to the load data section at the overload. [-OL] is put out to the load
data section when Gross value is
in the minus condition.
• The empty sections are all spaces.
113
