39
Setting of Function
6-6.ZERO set
ZERO set function memorizes a present measuring value as ZERO when the indicated value
of the load display section is the gross display and within the effective range of ZERO set,
and adjust the display to zero. This function is used by pushing [F/ENTER] key allocated (Refer
to function F-55), or used as the external control after allocating to the external control input
(Refer to func
tion F-60 ~ F-62).
6-6-1.Operating condition of ZERO set
ZERO set operating condition is selected by C function CF-10.
Setting range : 0,1
0：Operation at steady
1：Unconditional operation
6-6-2.ZERO set effective range
ZERO set effective range is set by C function CF-11.
The effective range is common both for ZERO set and ZERO tracking.
Setting range : 00 ～ 30
：02
Unit : ± 1 % of weighing capacity OFF：00
6-7. ZERO tracking
ZERO tracking is the function that the compensation of gradual zero drifts in a constant
condition and ZERO is stabilized.
6-7-1. Target of ZERO tracking
The target of ZERO tracking is selected by C function CF-12.
Setting range：0,1
0：Gross value and Net value (Against the load display)
1：Gross value (When gross weight is displayed)
6-7-2. Data width of ZERO tracking
The data width of ZERO tracking is set by C function CF-13.
Setting range : 000 ～ 999
：000
Unit : 0.1 DOFF：000
• When the ZERO compensation in effective range for ZERO set and ZERO tracking
is executed, ZERO set is not accepted.
• When tare weight cancellation is executed, ZERO set is executed after clearing
tare weight cancellation.
