③ Setting of Decimal point display position (4-6. Step 3)
④ Setting of Scale interval (4-6. Step 4)
① Change to Calibration mode by communication (4-6. Step 1)
② Setting of Unit (4-6. Step 2)
⑤ Setting of Measuring value (4-6. Step 5)
⑥ Setting of mass of weight (4-6. Step 6)
In the calibration by numeric input
(Electrical calibration)
In the calibration by actual weight
(Calibration by actual weight)
⑬ Calibration is finished (4-6. Step 9)
⑦ Confirmation of stable at ZERO (4-6. Step 7)
⑧ ZERO calibration by measuring value (4-6. Step 7)
⑩ Confirmation of stable of SPAN (4-6. Step 8)
⑪ SPAN calibration by weight.
⑨ ZERO calibration by numeric input (4-6. Step 7)
⑫ SPAN calibration by numeric input (4-6. step 8)
16-5. Data format of calibration by transmission
The procedure of the calibration by communication is as shown in the following flow chart.
Each item of the flow chart corresponds to each procedure of [4-6. Calibration procedure
details]. Please refer [4-6. Calibration procedure details] for the details.
• While executing the calibration by transmission,
(-RS-) is displyed.
• Please refer [16-3. ⑫ Error processing for communication] for the details of error
command in calibration by communication].
• When the calibration is compulsorily finished, all the data returns to the condition
before the calibration without executing the registration.
• Please register the data for the calibration with the weight after confirming the
stable condition without
fail.
