• The load data enters from the right.
• The sign of [-] for minus and [+] for plus is entered.
• The load data performs zero suppress.
• Please do not put the decimal point to the set data in the calibration by
communication.
• [OL] is put out to the load data section at the overload. [-OL] is put out to the load
data section when Gross value is in the minus condition.
• The empty sections are all spa
ces.
① Change to communication calibration mode (Host → CSD-892-73)
2 4 6 8 10 12 14 16
@ 0 0 9 0 0 1 Terminator
In normal operation
Return (CSD-892-73 → Host)
2 4 6 8 10 12 14 16
@ 0 0 9 0 0 1 Terminator
In abnormal operation
Return (CSD-892-73 → Host)
2 4 6 8
@ 0 0 E R 1 3 Terminator
When the calibration lock is effective.
Return (CSD-892-73 → Host)
2 4 6 8
@ 0 0 E R 0 2 Terminator
Spaces
Command No.
Number
Command No.
Number
Spaces
128
USB (RS-232C)
