49
Setting of Function
8.
Various operations by function data
8-1. Digital filter
The function of digital filter is a steady of A/D converted data by the running average
processing.
The running average frequency is selected by the setting of function F-01.
Setting range：001 ～ 512
：016
Unit：1 times
The tendency to the characteristic by running average is shown in the table below.
Running average frequency Little Much
Noise proof Sharpness Stable
Response speed Quick Slow
8-2. Analog filter
The function of analog filter cancels the noise of the input signal by filtering.
The frequency is selected by the setting of function F-02.
Setting range：0 ～ 4
0：2Hz 1：4Hz
2：6Hz
3：8Hz 4：10Hz
8-3. Stabilization filter
The function of stabilization filter increases the digital filter when the change width of load
display is within a constant, and also that condition continues longer than the fixed time.
8-3-1. Stabilization filter
The moving average frequency for the stabilization filter is selected by the setting of
function F-05.
Setting range
：001 ～ 512 ：092
Unit：1 times
8-3-2. Data width of stabilization filter
The data width of stabilization filter is set by function F-06.
Setting range：0000 ～ 9999
：0020
Unit：0.1D OFF：0000
8-3-3. Time width of stabilization filter
The time width of stabilization filter is set by function F-07.
Setting range：00 ～ 99
：05
Unit：0.1 s OFF：00
