48
Setting of Function
Reference No. Item Function No. Set value Contents
8-8-2
Operation of external
control output
(OUTPUT1)
F-70
● 00 OFF
01 STABLE
02 DURING TARE WEIGHT CANCELLATION
03 DISPLAY GROSS VALUE
04 DISPLAY NET VALUE
05 CENTER ZERO
06 DURING HOLD
07 ERROR
08 CAPACITY EXCEED ERROR
09 NEAR ZERO
10 OK (S0)
11 FULL FLOW (S1)
12 MIDIUM FLOW (S2)
13 DRIBBLE FLOW (S3)
14 OVER (S4)
15 UNDER
16 FULL
17 RUN (DURING MEASUREMENT)
8-8-2
Operation of external
contro
l output
(OUTPUT2)
F-71 Selectable as well as F-70
8-8-2
Operation of external
control output
(OUTPUT3)
F-72 Selectable as well as F-70
8-8-2
Operation of external
control output
(OUTPUT4)
F-73 Selectable as well as F-70
8-8-2
Operation of external
control output
(OUTPUT5)
F-74 Selectable as well as F-70
8-8-3
OUTPUT LOGIC for
external control output
F-83
00000
~11111
● 00000
0 : INVALID
1 : VALID
10
0
digit : Display
10
1
digit : Comparative result
10
2
digit : Gross / Net data of CC-Link interface.
14-3-1
Occupied terminal number
of CC-Link interface
F-84
0
1
● 2
14-3-2
Terminal number of
CC-Link interface
F-85
01~64
● 01
14-3-3
Baud rate of CC-Link
interface
F-86
● 0
1
2
3
4
14-3-4
32 bit data representation
method for CC-Link
interface
F-87
● 0
1
8-9 Maintenance date F-90 Don't use here.
8-9 Maintenance number F-91 Don't use here.
8-10
Turning
ON time of liquid
crystal back light
F-95
00~60
● 00
8-11 Function clear F-99 The content of function set is returned to the setting of default.
● : default
