47
Setting of Function
Reference No. Item Function No. Set value Contents
16-2-1
Operation mode of USB
(RS-232C)
F-40
● 0 Command mode
1 Stream mode
16-2-2
Output target in stream
mode of USB (RS-232C)
F-41
(effective at
F-40=1)
● 0
Synchronizing with display
(HOLD at HOLD signal ON)
1 Gross value
2 Net value
3 Load display data with condition
16-2-3
USB (RS-232C)
Specifications for
Communication
F-42 ● 13020
Data bit length
10
0
digit : ● 0 = 7 bit, 1 = 8 bit
Parity
10
1
digit : 0 = No parity, 1 = Even parity,
● 2 = Odd parity
Stop bit
10
2
digit : ● 0 = 1 bit, 1 = 2 bit
Baud rate
10
3
digit : 0 = 1 200 bps, 1 = 2 400 bps,
2 = 4 800 bps, ● 3 = 9 600 bps,
4 = 19 200 bps, 5 = 38 400 bps
Terminator
10
4
digit : 0 = CR, ● 1 = CR+LF
16-2-4
USB (RS-232C) decimal
point for communication
data
F-46
● 0 Nothing
1 Existin
g
16-2-5
USB (RS-232C)
number of digit for
communication data
F-49
● 0 Unit : 2 digits
1 Unit : 3 digits
8-7
Operation of
[F/ENTER] key
F-55
0 Nothing
1 HOLD
2 ZERO set
3 ZERO clear
4 Tare weight cancellation
5 Tare weight cancellation clear
6 Changeover of Net / Gross value
7 Shift to the setting mode of comparison
● 8 Confirming terminal number of CC-Link interface
8-8-1
Operation of INUPT1 of
external control input
F-60
● 00 OFF
01 ZERO set
02 ZERO clear
03 Tare weight cancellation
04 Tare weight cancellation clear
05 Changeover of Net / Gross value
06 HOLD (Pulse)
07 HOLD (Level)
08 Display of net value (Level :
09
Batched key lock (Level : This becomes effective at ON
while measuring screen is displayed.)
10 ERROR release.
8-8-1
Operation of INUPT2 of
external control input
F-61 Selectable as well as F-60
8-8-1
Operation of INUPT3 of
externa
l control input
F-62 Selectable as well as F-60
● : default
