Setting of Function
7-2. Details of function data
Reference No. Item Function No. Set value Contents
8-1 Digital filter F-01
001 ~ 512
● 016
Unit : Moving average time 1 time
8-2 Analog filter F-02
0 2 Hz
● 1 4 Hz
2 6 Hz
3 8 Hz
4 10 Hz
8-3-1 Stabilization filter F-05
001~512
● 092
Unit : Moving average time 1 time
8-3-2
Data width of stabilization
filter
F-06
0000~9999
● 0020
Unit : 0.1D
0000 : Stabilization filter is OFF.
8-3-3
Time width of stabilization
filter
F-07
00~99
● 05
Unit : 0.1 s
ec.
00 : Stabilization filter is OFF.
8-4-1 Independent key lock F-08
0000~1111
● 0000
0 : INVALID
1 : VALID
10
0
digit : [F/ENTER] key
10
1
digit : [CAL-S/ ] key
10
2
digit : [CAL-Z/ ] key
10
3
digit : [FUNC.] key
8-5-1
Data width of stability
detection
F-10
000~999
● 020
Unit : 0.1D
0000 : Stability detection is OFF.
8-5-2
Time width of stability
detection
F-11
00~99
● 10
Unit : 0.1 sec.
0000 : Stability detection is OFF.
8-6 Target of hold F-18
000~111
● 111
0 : INVALID
1 : VALID
10
0
digit : Display
10
1
digit : Comparative result
10
2
digit : Gross / Net data of CC-Link interface.
11-3-4
Operating
target of
5-steps comparator
F-21
00000
~22222
● 00000
0 : Synchronizing with display
1 : Gross value
2 : Net value
10
0
digit : Operating target of S0
10
1
digit : Operating target of S1
10
2
digit : Operating target of S2
10
2
digit : Operating target of S3
10
2
digit : Operating target of S4
11-3-3
Operating condition of
5-steps comparator
F-22
00000
~22222
● 00000
0 : OFF
1 : Setting value or more
2 : Sett
ing value or less
10
0
digit : Operation of S0
10
1
digit : Operation of S1
10
2
digit : Operation of S2
10
2
digit : Operation of S3
10
2
digit : Operation of S4
11-3-5
Operating condition of
comparator hysteresis
F-24
● 0 On-Delay
1 Off-Delay
11-3-5
Data width of comparator
hysteresis
F-25
00~99
● 00
Unit : 1D
(00 : Hysteresis OFF
11-3-5
Time width of comparator
hysteresis
F-26
00~99
● 00
Unit : 1 sec.
(00 : Hysteresis
OFF
