① Special data area (4 stations, 2 stations)
When the set value is registered by using the set value writing request (Request 1), the
set value is set in each area.
Details of each set value are shown as follows;
Data type Setting range
Final 32 bit binary with sign 0 ~ 999999
Preliminary 2 32 bit binary with sign 0 ~ 999999
Preliminary 1 16 bit binary with sign 0 ~ 32767
Free Fall 16 bit binary with sign -32767 ~ 32767
Over 16 bit binary with sign 0 ~ 32767
Under 16 bit binary with sign 0 ~ 32767
Full 32 bit binary with sign 0 ~ 999999
Near Zero 32 bit binary with sign 0 ~ 999999
② General data area (4 stations, 2 stations)
When the set value or data is registered by using the general command request (request 2),
the set value is set in this area.
Data type : 32 bit binary with sign
Setting range : Depends on the set value
③ Command No. (4 stations, 2 stations)
When the set value or data is registered by using the general command request (request 2),
the command No. is set in this area.
The content of the general data area
is set depending on the command set in this
command area.
Data type : 8 bit binary
Setting range : 0 ~ 255
④ Operation mode (4 stations, 2 stations)
When the operation mode is changed by using the operation mode changeover request
(request 3), the mode number is set in this area.
This function is prepared for future expansion.
Data type : 8 bit binary
Setting range : ~ 255
82
CC-Link
