① Special data area (4 stations, 2 stations)
When the set value is registered by using the setting value writing request (request 1), the
set value is set in each area.
Details of each set value are shown as follows;
Data type Setting range
S1 32 bit binary with sign -999999 ~ 999999
S2 32 bit binary with sign -999999 ~ 999999
S3 32 bit binary with sign -999999 ~ 999999
S4 32 bit binary with sign -999999 ~ 999999
Full 32 bit binary with sign 0 ~ 999999
Near Zero 32 bit binary with sign 0 ~ 999999
② General data area (4 stations, 2 stations)
When the set value or data is registered by using the general command request (request 2),
the set value is set in this area
Details of each set value are shown as follows;
Data type Setting range
S0 32 bit binary with sign -999999 ~ 999999
S1 32 bit binary with sign -999999 ~ 999999
S2 32 bit binary with sign -999999 ~ 999999
S3 32 bit binary with sign -999999 ~ 999999
S4 32 bit binary with sign -999999 ~ 999999
Full 32 bit binary with sign 0 ~ 999999
Near Zero 32 bit binary with sign 0 ~ 999999
③ Command No. (4 stations, 2 stations)
When the set value or data is registered by using the general command request (request 2),
the command No. is set in this area.
The content of the general data area is set depending on the command set in this
command area.
Data type : 8 bit binary
Setting range : 0 ~ 255
④ Operating mode (4 stations, 2 stations)
When the operation mode is changed by using the operation mode changeover request
(request 3), the mode number is set in this area.
This functi
on is prepared for future expansion.
Data type : 8 bit binary
Setting range : 0 ~ 255
84
CC-Link
