① Net value (4 stations)
Area for displaying the net value.
Data type : 32 bit binary with sign
Setting range : -99999 ~ 99999
② Gross value (4 stations)
Area for displaying the gross value.
Data type : 32 bit binary with sign
Setting range : -99999 ~ 99999
③ Error code (4 stations, 2 stations, 1 station)
Area for displaying the error generating in the main body of CSD-892-73.
Refer to [ ④ Error assistanc
e code] for the contents of error code.
Data type : 16 bit binary
Setting range : 0 ~ 255
④ Error assistance code (4 stations, 2 stations, 1 station)
Area for displaying the error generating in the main body of CSD-892-73.
Data type : 16 bit binary
Setting range : 0 ~ 255
Error code Error assistance code Contents
0 0
1
Weighing sequence
error
Undefined Undefined
2
(ZERO set error)
1
ZERO set error
In case of execute ZERO out of range of zero.
2
Tare weight cancellation error
In case of execute tare weight cancellation under the
condition of being not able to execute it.
3
(Other error)
3 A/D conversion error
31 EEPROM writing error.
32 EEPROM reading error.
99 Except for the measurement
mode.
4
(Calibration error)
0 TE-L error
1 TE-H error
2 SP-L error
3 SP-H error
99
(Setting Error)
0
Receiving undefined command
When undefined data is set at command No.
1 Error outside setting range
2 Error that cannot be executed.
• Please refer to [19. Error display] for the contents of error code.
88
CC-Link
