10. Usage
MiR100 Hook User Guide (en) 10/2020 - v.3.0 ©Copyright 2016-2020: Mobile Industrial Robots A/S. 153
Pos. Description Pos. Description
A Cart width: between 400 mm
and 1500 mm
B Cart length: between 500 mm
and 2400 mm
C Cart height: maximum 1800 mm D Locked wheels offset: the
locked wheels offset is the
distance from the gripping
point of the cart to the locked
wheels axis.
Table 10.1.
Cart measurements.
For more information, see Cart specifications on page94.
