5 - 10
5.3 Utility Package Operation
5.3.2 Operation overview
5
UTILITY PACKAGE (GX Configurator-AD)
[Online] – [Monitor/Test]
Selecting monitor/test module window
Monitor/Test window
Refer to Section 5.6.
Select a module to be monitored/tested.
1)
FB conversion window
<<FB support parameter>> tab –
Refer to Section 5.7.
FB conversion window
