7
ONLINE MODULE CHANGE
7.5 Precautions for Online Module Change
7 - 38
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
SETUP AND PROCEDURES BEFORE OPERATION
5
UTILITY PACKAGE (GX CONFIGURATOR- AD)
6
PROGRAMMING
7
ONLINE MODULE CHANGE
8
TROUBLESHOOTING
7.5 Precautions for Online Module Change
The following are the precautions for online module change.
(1) Always perform an online module change in the correct procedure. A failure to do so
can cause a malfunction or failure.
(2) If an online module change is made with the user range setting, the accuracy after that
will fall to about less than three times of the accuracy before that.
Re-set the offset/gain values as necessary.
(3) During an online module change, do not perform the operations below. If they are per-
formed, the A/D converter module may not operate normally.
• Powering off the programmable controller CPU
• Resetting the programmable controller CPU
