Mitsubishi Electric GX Configurator-AD (SW2D5C-QADU-E) User Manual

6
PROGRAMMING
6.2 For Use in Normal System Configuration (Q68AD-G)
6.2.3 Programming example without using the utility package
6 - 8
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
SETUP AND PROCEDURES BEFORE OPERATION
5
UTILITY PACKAGE (GX CONFIGURATOR- AD)
6
PROGRAMMING
7
ONLINE MODULE CHANGE
8
TROUBLESHOOTING
6.2.3 Programming example without using the utility package
(1) List of devices
Device Function
D1 CH1 Digital output value
D2 CH2 Digital output value
D3 CH3 Digital output value
M0 to M2 A/D conversion completed flag
M100 Module ready check flag
M12,M13 CH2 Warning output flag (Process alarm)
M34,M35 CH3 Warning output flag (Rate alarm)
M50 CH1 Input signal error detection flag
X0 Module ready
Q68AD-G (X/Y0 to X/YF)
X9 Operating condition setting completed flag
XC Input signal error detection signal
XE A/D conversion completed flag
XF Error flag
Y9 Operating condition setting request
YF Error clear request
X10
Digital output value read command input
signal
QX10 (X10 to X1F)
X11 Input signal error detection reset signal
X12 Error reset signal
Y20 to Y2B Error code display (BCD 3 digits) QY10 (Y20 to Y2F)
