PROGRAMMING
6.3 For Use in Remote I/O Network (Q68AD-G)
6.3.1 Programming example using the utility package
6 - 14
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
SETUP AND PROCEDURES BEFORE OPERATION
5
UTILITY PACKAGE (GX CONFIGURATOR- AD)
6
PROGRAMMING
7
ONLINE MODULE CHANGE
8
TROUBLESHOOTING
6.3.1 Programming example using the utility package
(1) Operating GX Developer
(a) CPU parameter setting
Network type
: MNET/H (Remote master)
Starting I/O No.
: 0000
H
Network No.
:1
Total stations
:1
Mode
: Online
Network range assignment
:
Refresh parameters
:
